Model | DP15HCI | DP20HCI | DP30HCI | DP30HHCI | DP30HDCI |
Suction&Discharge port size(mm/inch) | 40mm(1.5") | 50mm(2") | 80mm(3") | 80mm(3") | 80mm(3") |
Engine Type | Single-Cylinder, Vertical, 4-Stroke, Air-Cooled Diesel Engine | ||||
Engine Model | 178F | 186FA | 186FA | 188FA | 192FB |
Cont.Head(m) | 75 | 90 | 75 | 105 | 60 |
Max Suction Head(m) | 8 | ||||
Cont.capacity(m³/Hr) | 28 | 35 | 47 | 42 | 90 |
Fuel Tank(L) | 13.5L | 13.5L | 13.5L | 13.5L | 13.5L |
Starting System | Recoil & Eletric Start With Battery | ||||
Standard Features | Tube/Hose Connector, Filter, Seal Ring, Hoop, Tool Bag, Manual. | ||||
Optional Features | Wheels kit | ||||
Dimension(mm) | 645x475x605 | 645x475x605 | 645x475x605 | 645x475x605 | 645x475x605 |
Dry weight(kg) | 75 | 80 | 85 | 90 | 95 |
