Model | DP20(E) | DP30(E) | DP40(E) | DP60(E) | ||
Pump | Inlet | mm | 50 | 80 | 100 | 150 |
Outlet | mm | 50 | 80 | 100 | 150 | |
Elevation head | m | 26 | 28 | 31 | 15 | |
Engine | flow | m³/h | 36 | 50 | 96 | 180 |
mode name | 173F | 178F | 186FA | 192FC | ||
max power | HP | 4 | 6 | 9 | 12 | |
Speed | rpm | 3600 | 3600 | 3600 | 3600 | |
capacity | cc | 246 | 296 | 418 | 498 | |
fuel tank | L | 2.5 | 3.5 | 5.5 | 5.5 | |
G.W|N.W | kg | 50/48 | 58/56 | 75/73 | 75/73 | |
dimension | mm | 510*420*545 | 580*450*580 | 660*480*620 | 660*480*620 |
