Model | WP20 | WP30 |
Outlet size (mm) | 50 (2 inches) | 80 (3 inches) |
Import size (mm) | 50 (2 inches) | 80 (3 inches) |
Speed (rpm) | 3600 | 3600 |
Displacement (m3/h) | 35 | 60 |
Head (m) | 30 | 20 |
Suction (m) | 7 | 7 |
Engine model | NL168F-1 | NL170F |
Displacement (cm3) | 196 | 210 |
Compression ratio | 8.5:1 | 8.5:1 |
Maximum output power (HP/rmp) | 6.5/3600 | 7/3600 |
Maximum torque (Nm) | 13.2 | 14 |
Fuel tank capacity (L) | 3.6 | 3.6 |
Minimum fuel consumption (g/Kw.h) | 395 | 395 |
Engine oil capacity (L) | 0.6 | 0.6 |
