pressure pump | Motor | features | |||||||||
TYPE | PUMP model | Max pressure | Working Pressure | Flow Rate | Power | voltage | Speed | Pressure Hose | wheel size | G.W | N.W | dimension |
bar|PSI | bar|PSI | LPM|GPM | Kw | V | rpm | M | inch | kg | mm | ||
ES1.8-2 | PE130 | 130/1885 | 100/1450 | 6.5/2 | 1.8 | 220 | 2800 | 8 | 8 | 28/26 | 620*450*490 |
ES2.2-2 | PE200 | 130/1885 | 100/1595 | 12.6/3.4 | 2.2 | 220 | 2800 | 10 | 10 | 47/44 | 770*480*360 |
ES/ET2.2-4 | PE200 | 130/1885 | 100/1450 | 12.6/3.4 | 2.2 | 220/380 | 1450 | 10 | 10 | 53/50 | 770*480*360 |
ES/ET3-4 | PE200 | 170/2465 | 140/2030 | 12.6/3.4 | 3 | 220/380 | 1450 | 10 | 10 | 55/52 | 770*480*360 |
